Section 8
PARTS LIST
61
8.11 AFTERCOOLER PIPING (WATER-COOLED)
key part
number description number quantity
1 bushing, reducing hex 2” x 1 1/4” 802108--050 2
2 nipple, pipe 1 1/4” x 6” 822120--060 1
3 elbow, tube--M 1 1/4” x 1 1/4” 810520--125 3
4 elbow, pipe 1 1/4” 801515--050 1
5 connector, tube 1 1/4” x 1 1/4” 810220--125 1
6 tube, water inlet to cooler 1 1/4” 02250052--330 1
7 tube, water outlet 1 1/4” 02250052--326 1
8 bushing, reducing hex 1 1/2” x 1 1/4” 802106--050 4
9 nipple, pipe 1 1/4” x 4” 822120--040 2
10 tube, aftercooler to fluid cooler 1 1/4” 02250052--328 1
11 elbow, tube--F 1 1/4” x 1 1/4” 810420--125 2
12 cooler , fluid 02250114--977 1
13 aftercooler 043009 1
14 screw, hex ser washer 3/8”--16 x 1” 829706--100 8
15 nut, hex flange 3/8”--16 825306--347 8
16 support, cooler separator end 02250051--862 1
17 connector, tube--M 2” x 2” 810232--200 1
18 tube, minimum pressure valve to cooler 2” 02250052--119 1
19 elbow, tube--M 2” x 2” 810532--200 1
20 support, cooler motor end 02250115--734 1
21 nipple, pipe 2” x close 822232--000 4
22 union, pipe 2” 802515--080 1
23 elbow, pipe 2” 801515--080 1
24 separator, moisture 2”
(I)
02250100--365 1
25 U--bolt, 3/8” x 2 1/2” 868306--250 1
26 connector, tube--M 1/4” x 1/4” 810204--025 1
27 bushing, reducing hex 1/2” x 1/4” 802102--010 1
28 tee, reducing 2” x 2” x 1/2” 802208--082 1
29 support, moisture separator 02250115--692 1
(I)
For maintenance on moisture separator no. 02250100-365, order repair kit no. 250031--245.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUM BER OF COMPRESSOR
