Sullair TS-20 Series User Manual

Section 7
ILLUSTRATIONS AND PARTS LIST
33
7.3 MOTOR, COMPRESSOR AND FRAME --- 100, 125, 150 & 200HP/75, 93, 112 & 150KW
key part
number description number quantity
1 frame, assy 250027---308 1
6 shim set, motor mtg. 020293 4
8 motor, 100HP/75KW
(I)
1
S
motor, 125HP/93KW
(I)
1
S
motor, 150HP/112KW
(I)
1
S
motor, 200HP/150KW
(I)
1
9 grip, cord #1/0 (100HP/75KW) 250014--- 560 2
S
grip, cord #1/0
(125 & 150HP/93 & 112KW) 250014---561 2
grip, cord #4/0 (200HP/150KW) 250014---564 2
10 wire, type g---gc #1 ga (100HP/75KW) 250014---309 4 ft.
S
wire, type g---gc #1/0 (125HP/93KW) 250014---310 4 ft.
S
wire, type g---gc #2/0 (150HP/112KW) 250014---311 5 ft.
S
wire, type g---gc #4/0 (200HP/150KW) 250014---313 4.5ft.
11 element, coupling
(100 & 125HP/75 & 93KW) 406632 1
S
element, coupling (150HP/112KW) 406631 1
S
element, coupling (200HP/150KW) 046999 1
12 hub, coupling (100 & 125HP/75 & 93KW) 407988 2
S
(150HP/112KW) 407988 1
S
(200HP/150KW) 250004---635 1
13 bar, motor support
(100,125 & 200HP/75, 93 & 150KW) 028084 4
14 guard, coupling 225907 1
(I)
Motormayvaryforeachcompressor.Consultfactorywithmachineserialnumber.
(Continued on Page 35)
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
