Section 7
ILLUSTRATIONS AND PARTS LIST
35
7.3 MOTOR, COMPRESSOR AND FRAME --- 100, 125, 150 & 200HP/75, 93, 112 & 150KW (Continued)
key part
number description number quantity
18 compressor, unit
(II)
--- 1
19 bar, unit support 250032---544 1
(150HP/112KW) 407985 1
S
(200HP/150KW) 250021---401 1
(100 & 125HP/75 & 93KW) 044763 1
(100 &125HP/75 & 93KW) 046389 1
(II)
There is an exchange program whereby a remanufactured compressor unit can be obtained
from Sullair distributors or the factory at less cost than the owner could repair the unit. For infor-
mation regarding the unit exchange program, contact your nearest Sullair representative or the
Sullair Corporation.
The shaft seal is not considered part of the compressor unit in regard to the two year warranty.
The normal Sullair parts warranty applies. For shaft seal repairs order replacement seal kit no.
02250049---020.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
