Section 7
ILLUSTRATIONS AND PARTS LIST
45
7.8 COMPRESSOR COOLING AND LUBRICATION SYSTEM --- 125 & 150HP/93 & 112KW (AIR---COOLED)
key part
number description number quantity
7 cooler, combination fluid and after 250022---529 1
(I)
040648 1
23 support, moisture separator 250023---077 2
27 separator, water (125 &150HP/93 &112KW) 410144 1
(II)
040327 2
(Continued on Page 47)
(I)
For maintenance on flexible coupling no. 040648, order replacement gasket no. 040649 (2 required).
(II)
For maintenance on flexible coupling no. 040327, order replacement gasket no. 040523 (2 required).
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
