Section 7
ILLUSTRATIONS AND PARTS LIST
67
7.13 COMPRESSOR COOLING AND LUBRICATION SYSTEM---200HP/150K W (WATER---COOLED)
(Continued)
key part
number description number quantity
43 filter, fluid
(III)
250007---219 1
47 valve, fluid stop
(IV)
016742 1
49 tube, steel 841015---004 20 ft.
(III)
For maintenance on fluid filter no. 250007---219, order repair kit no. 250008---956.
(IV)
For maintenance on fluid stop valve no. 016742, order repair kit no. 001684.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
To Next Page
