Section 7
ILLUSTRATIONS AND PARTS LIST
75
7.15 COMPRESSOR DISCHARGE SYSTEM --- 100, 125 & 150HP/75, 93 & 112KW (Continued)
key part
number description number quantity
S
(125 & 150HP/ 93 & 112KW) 822864---110 1
61 separator, primary 250034---121 1
(VI)
040327 1
S
(125 & 150HP/93 &112KW)
(VII)
041085 1
S
(125 & 150HP/93 &112KW) 822864---120 1
S
(125&150HP/93 &112KW) 822264---000 1
67 tank, fluid (100HP) 248585 1
S
tank, fluid (125 & 150HP/93 &112KW) 250020---340 1
S
(125 & 150HP/93 &112KW) 822148---040 1
(VI)
For maintenance on flexible coupling no. 040327, order replacement gasket no. 040523 (2 required).
(VII)
For maintenance on flexible coupling no. 041085, order replacement gasket no. 041353 (2 required).
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUMBER OF COMPRESSOR
To Next Page
