Sumitomo HF-520 - Fault Contents Details

10 CC-Link Code Numbers
31
122H
(1015H)
Fault contents 3
0 MEMOBUS communication fault (CE) 0021H
1 Option communications error (bUS) 0022H
2 Reserved –
3 Reserved –
4 Control fault (CF) 0025H
5 Reserved –
6 Option unit external fault (EF0) 0027H
7 PID feedback loss (FbL) 0028H
8 Undertorque detection 1 (UL3) 0029H
9 Undertorque detection 2 (UL4) 002AH
A High Slip Braking overload (oL7) 002BH
B Reserved –
C Reserved –
D Reserved –
E Reserved –
F Hardware fault (including oFx) 0030H
123H
(1016H)
Fault contents 4
0 Reserved –
1 Reserved –
2 Reserved –
3 Reserved –
4 Reserved –
5 Output current imbalance (LF2) 0036H
6 Pullout detection (STo) 0037H
7 Reserved –
8 Reserved –
9 Reserved –
A Too many speed search restart (SEr) 003BH
B Reserved –
C Reserved –
D Reserved –
E Reserved –
F Reserved –
124H
(1017H)
Fault contents 5
0 Excessive PID feedback (FbH) 0041H
1 External fault (input terminal S1) (EF1) 0042H
2 External fault (input terminal S2) (EF2) 0043H
3 Mechanical weakening detection 1 (oL5) 0044H
4 Mechanical weakening detection 2 (UL5) 0045H
5 Current offset fault (CoF) 0046H
6 Reserved –
7 Reserved –
8 Reserved –
9 Reserved –
A Reserved –
B Reserved –
C Reserved –
D Reserved –
E Reserved –
F Reserved –
Extended Command Code
(Monitor Code)
Fault Name
Fault Code (U2, U3)
BIT
