10 CC-Link Code Numbers

130H

(101CH)

CPF contents 1

0 Reserved –

1 Reserved –

2 A/D conversion error (CPF02) 0083H

3 PWM data error (CPF03) 0084H

4 Reserved –

5 Reserved –

6 EEPROM data error (CPF06) 0087H

7 Terminal board communication error (CPF07) 0088H

8 EEPROM serial communication fault (CPF08) 0089H

9 Reserved –

A Reserved –

B RAM fault (CPF11) 008CH

C Flash memory fault (CPF12) 008DH

D Watchdog circuit exception (CPF13) 008EH

E Control circuit fault (CPF14) 008FH

F Reserved –

131H

(101DH)

CPF contents 2

0 Clock fault (CPF16) 0091H

1 Timing fault (CPF17) 0092H

2 Control circuit fault (CPF18) 0093H

3 Control circuit fault (CPF19) 0094H

4 Hardware fault at power up (CPF20) 0095H

5 Hardware fault at communication start up (CPF21) 0096H

6 A/D conversion fault (CPF22) 0097H

7 PWM feedback fault (CPF23) 0098H

8 Drive capacity signal fault (CPF24) 0099H

9 Reserved –

A Reserved –

B Reserved –

C Reserved –

D Reserved –

E Reserved –

F Reserved –

Extended Command Code

(Monitor Code)

Fault Name

Fault Code (U2, U3)
