SUMMERS MANUFACTURING CO., INC. APPLICATION RATE CHART (ENGLISH)
U.S. GALLONS PER ACRE - 20" SPACING
TIP NO.
Color
Screen
PSI
Capacity 1
Nozzle in
GPM oz/min
SPEED - MPH
5 6 7 8 10 12
8001
11001
Orange
100
mesh
Green
15 .06 / 8 3.6 3.0 2.6 2.3 1.8 1.5
20 .07 / 9 4.2 3.5 3.0 2.6 2.1 1.8
30 .09 / 11 5.3 4.5 3.7 3.2 2.6 2.1
40 .10 / 13 5.9 5.0 4.2 3.7 3.0 2.5
50 .11 / 14 6.5 5.4 4.7 4.1 3.3 2.7
60 .12 / 15 7.1 5.9 5.1 4.5 3.6 3.0
*75 .14 / 18 8.3 6.9 5.9 5.2 4.2 3.5
*90 .15 / 19 8.9 7.4 6.4 5.6 4.5 3.7
80015
110015
Green
100
mesh
Green
15 .09 / 12 5.3 4.5 3.8 3.3 2.7 2.3
20 .11 / 14 6.5 5.4 4.7 4.1 3.2 2.6
30 .13 / 17 7.7 6.4 5.5 4.8 3.9 3.2
40 .15 / 19 8.9 7.4 6.4 5.6 4.5 3.7
50 .17 / 22 10.1 8.4 7.2 6.3 5.0 4.2
60 .18 / 23 10.7 8.9 7.6 6.7 5.5 4.6
*75 .21 / 27 12.5 10.4 8.9 7.8 6.2 5.2
*90 .23 / 29 13.7 11.4 9.8 8.5 6.8 5.7
8002
11002
Yellow
50
mesh
Red
15 .12 / 15 7.1 5.9 5.1 4.5 3.5 3.0
20 .14 / 18 8.3 6.9 5.9 5.2 4.2 3.5
30 .17 / 22 10.1 8.4 7.2 6.3 5.0 4.2
40 .20 / 26 11.9 9.9 8.5 7.4 5.9 5.0
50 .22 / 28 13.1 10.9 9.3 8.2 6.5 5.4
60 .24 / 31 14.3 11.9 10.2 8.9 7.1 5.9
*75 .27 / 35 16.0 13.4 11.5 10.0 8.0 6.7
*90 .30 / 38 17.8 14.9 12.7 11.1 8.9 7.4
80025
110025
Lilac
50
mesh
Red
15 .15 / 19
8.9 7.4 6.4 5.6 4.5 3.7
20
.18 / 23 10.7 8.9 7.6 6.7 5.3 4.5
30
.22 / 28 13.1 10.9 9.3 8.2 6.5 5.4
40
.25 / 32 14.9 12.4 10.6 9.3 7.4 6.2
50
.28 / 36 16.6 13.9 11.9 10.4 8.3 6.9
60
.31 / 40 18.4 15.3 13.2 11.5 9.2 7.7
*75
.34 / 44 20.2 16.8 14.4 12.6 10.1 8.4
*90
.38 / 49 23.0 18.8 16.1 14.1 11.3 9.4
8003
11003
Blue
50
mesh
Red
15 .18 / 23 10.7 8.9 7.6 6.7 5.3 4.5
20 .21 / 27 12.5 10.4 8.9 7.8 6.2 5.2
30 .26 / 33 15.4 12.9 11.0 9.7 7.7 6.4
40 .30 / 38 17.8 14.9 12.7 11.1 8.9 7.4
50 .34 / 44 20.0 16.8 14.4 12.6 10.1 8.4
60 .37 / 47 22.0 18.3 15.7 13.7 11.0 9.2
*75 .41 / 52 24.0 20.0 17.4 15.2 12.2 10.1
*90 .45 / 58 27.0 22.0 19.1 16.7 13.4 11.1
8004
11004
Red
50
mesh
Red
15 .24 / 31 14.3 11.9 10.2 8.9 7.1 5.9
20 .28 / 36 16.6 13.9 11.9 10.4 8.3 6.9
30 .35 / 45 21.0 17.3 14.9 13.0 10.4 8.7
40 .40 / 51 24.0 19.8 17.0 14.9 11.9 9.9
50 .45 / 58 27.0 22.0 19.1 16.7 13.4 11.1
60 .49 / 63 29.0 24.0 21.0 18.2 14.6 12.1
*75 .55 / 70 33.0 27.0 23.0 20.0 16.3 13.6
*90 .60 / 77 36.0 30.0 25.0 22.0 17.8 14.9
8005
11005
Brown
50
mesh
Red
15 .31 / 40 18.4 15.3 13.2 11.5 9.2 7.7
20 .35 / 45 21.0 17.3 14.9 13.0 10.4 8.7
30 .43 / 55 26.0 21.0 18.2 16.0 12.8 10.6
40 .50 / 64 30.0 25.0 21.0 18.6 14.6 12.4
50 .56 / 72 33.0 28.0 24.0 21.0 16.6 13.9
60 .61 / 78 36.0 30.0 26.0 23.0 18.1 15.1
*75 .68 / 87 40.0 34.0 29.0 25.0 20.2 16.8
*90 .75 / 96 45.0 37.0 32.0 28.0 22.3 18.6
8006
11006
Gray
50
mesh
Red
15 .37 / 47 22.0 18.3 15.7 13.7 11.0 9.2
20 .42 / 54 25.0 21.0 17.8 15.6 12.5 10.4
30 .52 / 67 31.0 26.0 22.0 19.3 15.4 12.9
40 .60 / 77 36.0 30.0 25.0 22.0 17.8 14.9
50 .67 / 86 40.0 33.0 28.0 25.0 19.9 16.6
60 .73 / 95 44.0 36.0 31.0 27.0 22.0 18.2
8008
11008
White
50
mesh
Red
15 .49 / 63 29.0 24.0 21.0 18.2 14.5 12.0
20 .57 / 73 34.0 28.0 24.0 21.0 16.8 14.0
30 .69 / 88 41.0 34.0 29.0 26.0 21.0 17.2
40 .8 / 102 48.0 40.0 34.0 30.0 24.0 19.8
50 .89 / 113.5 53.0 44.0 38.0 33.0 27.0 22.0
60 .98 / 125 58.0 49.0 42.0 36.0 29.0 24.0
* TURBO TEEJET TIPS ARE RECOMMENDED FOR PRESSURES GREATER THAN 60PSI. BASED ON WATER @ 8.34 LB/GAL.
