SECTION 2 - SPRAYER OPERATION
* TURBO TEEJET TIPS ARE RECOMMENDED FOR PRESSURES GREATER THAN 4 KPA. BASED ON WATER @ 1 gm/cm
3
. 8Z1107 5/06
SUMMERS MANUFACTURING CO., INC. APPLICATION RATE CHART (METRIC)
LITERS PER HECTARE - .508 m (20") SPACING
TIP NO.
Color
Screen
KPA/100
(PSI)
Capacity 1
Nozzle in
L/min
SPEED - KM/HR (MPH)
8 (5) 10 (6.2) 12 (7.5) 14 (8.7) 16 (9.9) 18 (11.2)
8001
11001
Orange
100
mesh
Green
1.0 (14.5) .23 34.5 27.6 23.0 19.7 17.3 15.3
1.5 (21.8) .28 42.0 33.6 28.0 24.0 21.0 18.7
2.0 (29.0) .32 48.0 38.4 32.0 27.4 24.0 21.3
2.5 (36.3) .36 54.0 43.2 36.0 30.9 27.0 24.0
3.0 (43.5) .39 58.5 46.8 39.0 33.4 29.3 26.0
3.5 (50.7) .42 63.0 50.4 42.0 36.0 31.5 28.0
4.0 (58.0) .45 67.5 54.0 45.0 38.6 33.8 30.0
*5.0 (72.5) .50 75.0 60.0 50.0 42.9 37.5 33.3
*6.0 (87.0) .55 82.5 66.0 55.0 47.1 41.3 36.7
80015
110015
Green
100
mesh
Green
1.0 (14.5) .34 51.0 40.8 34.0 29.1 25.5 22.7
1.5 (21.8) .42 63.0 50.4 42.0 36.0 31.5 28.0
2.0 (29.0) .48 72.0 57.6 48.0 41.1 36.0 32.0
2.5 (36.3) .54 81.0 64.8 54.0 46.3 40.5 36.0
3.0 (43.5) .59 88.5 70.8 59.0 50.6 44.3 39.3
3.5 (50.7) .64 96.0 76.8 64.0 54.9 48.0 42.7
4.0 (58.0) .68 102.0 81.6 68.0 58.3 51.0 45.3
*5.0 (72.5) .76 114.0 91.2 76.0 65.1 57.0 50.7
*6.0 (87.0) .83 125.0 99.6 83.0 71.1 62.3 55.3
8002
11002
Yellow
50
mesh
Red
1.0 (14.5) .46 69.0 55.2 46.0 39.4 34.5 30.7
1.5 (21.8) .56 84.0 67.2 56.0 48.0 42.0 37.3
2.0 (29.0) .65 97.5 78.0 65.0 55.7 48.8 43.3
2.5 (36.3) .72 108.0 86.4 72.0 61.7 54.0 48.0
3.0 (43.5) .79 119.0 94.8 79.0 67.7 59.3 52.7
3.5 (50.7) .85 128.0 102.0 85.0 72.9 63.8 56.7
4.0 (58.0) .91 137.0 109.0 91.0 78.0 68.3 60.7
*5.0 (72.5) 1.02 153.0 122.0 102.0 87.4 76.5 68.0
*6.0 (87.0) 1.12 168.0 134.0 112.0 96.0 84.0 74.7
80025
110025
Lilac
50
mesh
Red
1.0 (14.5)
.57 84.2 67.3 56.1 48.1 42.1 37.4
1.5 (21.8)
.70 103 82.7 68.9 59.1 51.7 45.9
2.0 (29.0)
.81 120 95.7 79.7 68.3 59.8 53.1
2.5 (36.3)
.90 133 106 88.6 75.9 66.4 59.1
3.0 (43.5)
.99 146 117 97.4 83.5 73.1 65.0
3.5 (50.7)
1.07 158 126 105 90.3 79.0 70.2
4.0 (58.0)
1.14 168 135 112 96.2 84.2 74.8
*5.0 (72.5)
1.28 189 151 126 108 94.5 84.0
*6.0 (87.0)
1.40 207 165 138 118 103 91.9
8003
11003
Blue
50
mesh
Red
1.0 (14.5) .68 102.0 81.6 68.0 58.3 51.0 45.3
1.5 (21.8) .83 125.0 99.6 83.0 71.1 62.3 55.3
2.0 (29.0) .96 144.0 115.0 96.0 82.3 72.0 64.0
2.5 (36.3) 1.08 162.0 130.0 108.0 92.6 81.0 72.0
3.0 (43.5) 1.18 177.0 142.0 118.0 101.0 88.5 78.7
3.5 (50.7) 1.27 191.0 152.0 127.0 109.0 95.3 84.7
4.0 (58.0) 1.36 204.0 163.0 136.0 117.0 102.0 90.7
*5.0 (72.5) 1.52 228.0 182.0 152.0 130.0 114.0 101.0
*6.0 (87.0) 1.67 251.0 200.0 167.0 143.0 125.0 111.0
8004
11004
Red
50
mesh
Red
1.0 (14.5) .91 137.0 109.0 91.0 78.0 68.3 60.7
1.5 (21.8) 1.12 168.0 134.0 112.0 96.0 84.0 74.7
2.0 (29.0) 1.29 194.0 155.0 129.0 111.0 96.8 86.0
2.5 (36.3) 1.44 216.0 173.0 144.0 123.0 108.0 96.0
3.0 (43.5) 1.58 237.0 190.0 158.0 135.0 119.0 105.0
3.5 (50.7) 1.71 257.0 205.0 171.0 147.0 128.0 114.0
4.0 (58.0) 1.82 273.0 218.0 182.0 156.0 137.0 121.0
*5.0 (72.5) 2.04 306.0 245.0 204.0 175.0 153.0 136.0
*6.0 (87.0) 2.23 335.0 268.0 223.0 191.0 167.0 149.0
8005
11005
Brown
50
mesh
Red
1.0 (14.5) 1.14 171.0 137.0 114.0 97.7 85.5 76.0
1.5 (21.8) 1.39 209.0 167.0 139.0 119.0 104.0 92.7
2.0 (29.0) 1.61 242.0 193.0 161.0 138.0 121.0 107.0
2.5 (36.3) 1.80 270.0 216.0 180.0 154.0 135.0 120.0
3.0 (43.5) 1.97 296.0 236.0 197.0 169.0 148.0 131.0
3.5 (50.7) 2.13 320.0 256.0 213.0 183.0 160.0 142.0
.04.0 (58.0) 2.27 341.0 272.0 227.0 195.0 170.0 151.0
*5.0 (72.5) 2.54 381.0 305.0 254.0 218.0 191.0 169.0
*6.0 (87.0) 2.79 419.0 335.0 279.0 239.0 209.0 186.0
8006
11006
Gray
50
mesh
Red
1.0 (14.5) 1.37 206.0 164.0 137.0 117.0 103.0 91.3
1.5 (21.8) 1.68 252.0 202.0 168.0 144.0 126.0 112.0
2.0 (29.0) 1.94 291.0 233.0 194.0 166.0 146.0 129.0
2.5 (36.3) 2.16 324.0 259.0 216.0 185.0 162.0 144.0
3.0 (43.5) 2.37 356.0 284.0 237.0 203.0 178.0 158.0
3.5 (50.7) 2.56 384.0 307.0 256.0 219.0 192.0 171.0
4.0 (58.0) 2.74 411.0 329.0 274.0 235.0 206.0 183.0
8008
11008
White
50
mesh
Red
1.0 (14.5) 1.82 273.0 218.0 182.0 156.0 137.0 121.0
1.5 (21.8) 2.23 335.0 268.0 223.0 191.0 167.0 149.0
2.0 (29.0) 2.58 387.0 310.0 258.0 221.0 194.0 172.0
2.5 (36.3) 2.88 432.0 346.0 288.0 247.0 216.0 192.0
3.0 (43.5) 3.16 474.0 379.0 316.0 271.0 237.0 211.0
3.5
50.7
3.41 512.0 409.0 341.0 292.0 256.0 227.0
4.0 (58.0) 3.65 548.0 438.0 365.0 313.0 274.0 243.0
