SECTION 6 - OPTION NOTES AND INSTRUCTIONS
6.4
RINSE SYSTEM OPERATION
To fi ll tank using bottom fi ll
1. Rotate tank valve “A” to middle (closed) position.
2. If sprayer has combination bottom fi ll, verify that 2” bottom fi ll to main tank is closed.
3. Open 1-1/4” ball valve to rinse tank.
4. When rinse rank is full, close fi ll valve, and adjust tank valve “A” to desired position.
To fl ush sprayer tank
1. Adjust tank valve “A” right to receive clean water from rinse tank.
2. Rotate pump rinse valve “B” clockwise to direct water to sprayer tank rinse head.
3. Start and run pump for desired results.
To remove rinse water from main tank
1. Adjust tank valve “A” counter clockwise to receive dilute chemical solution from sprayer tank.
2. Rotate rinse valve “B” counter clockwise to direct chemical solution to sprayer booms. Booms must be turned
on and pump must be running.
3. Repeat as necessary to clean tank.
If sprayer is equipped with 2” bottom fi ll into the tank, the tank may be drained through the bottom fi ll into a
catch pan.
To fl ush booms only
1. Rotate tank valve “A” clockwise to receive clean water from rinse tank.
2. Rotate rinse valve “B” clockwise to direct rinse water to spray booms.
3. Start sprayer pump and adjust RPM to achieve adequate pressure for washing.
If there are further questions call Summers service department at 1-800-732-4392 ext. 2019.
6.6. VALVES “E” & “R” CROSS OVER PLUMBING OPTION
To install cross over plumbing on a summers pull-type sprayer.
Locate the front most capped off port on the discharge (plumbing attached to pump that feeds the booms) plumb-
ing. Install small elbow, clamp, gasket, and hose.
Locate a capped off port on suction line farthest from sprayer hitch. Attach ball valve and larger elbow using
clamps and gaskets supplied.
Attach the other end of hose installed in fi rst step to hose barb elbow just installed.
Fittings may be loosened and rotated to allow best path of fl ow from discharge to suction and to eliminate and
hose problems. Tighten all clamps
