SECTION 6 - OPTION NOTES AND INSTRUCTIONS
6.5
6.7. END NOZZLE OPTION
To bottom fi ll via the cross over plumbing.
Close the suction line ball valve that supplies water to pump from spray tank.
Open the bottom fi ll line ball valve so pump can suck from bottom fi ll line.
Open cross over plumbing ball valve to allow bottom fi ll water passage to sprayer tank.
Start sprayer pump to force water into spray tank.
To install a manual end nozzle on Summers sprayer.
Verify the end nozzle tip is installed and sized to match the boom spray tips (a selection chart is in the operator’s
manual for your sprayer.
Selected desired side of sprayer to mount end nozzle.
Remove wet boom end cap if installed.
Brush some pipe sealing compound on pipe threads and install end nozzle.
With nozzle installed adjust the spray direction to desired location.
Start sprayer and check for leaks, tip operation and spray pattern direction.
To install an electric end nozzle on Summers sprayer.
Verify the end nozzle tip is installed and sized to match the boom spray tips (there is a selection chart in your
sprayer operator’s manual).
Selected desired side of sprayer to mount end nozzle.
Remove wet boom end cap if installed.
Brush some pipe sealing compound on pipe threads and install end nozzle.
Attach wire harness to solenoid and route wires towards operator platform.
Tie or tape harness cable securely to sprayer and out of harms way. Be careful around pinch points and mov-
ing parts.
Attach harness to 450 control wiring if available. If all 450 harness switches are used then the end nozzle can
be run through any type of switch box that will provide a power supply and ground if one has not been provided
to you.
With nozzle installed adjust the spray direction to desired location.
Start sprayer, activate switch, check for leaks, tip operation and spray pattern direction.
End nozzle operation notes.
When end nozzle is operating the proper pattern will cover 6 feet and this must be considered additional width
when programming the Raven 450 sprayer control. If boom width is not entered correctly application rate
may not be accurate. Electric end nozzle harness should be plugged in to any available boom switch harness
on the 450 control harness. When the electric end nozzle is installed on the 450 console that boom switch will
automatically adjust spray pressure to meet the desired application rate for the width of sprayer booms that are
spraying.
