SECTION 6 - OPTION NOTES AND INSTRUCTIONS
6.6
6.8. SINGLE SEPARATE TIPLIFT CIRCUIT
1. Select tip lift cylinder to isolate – left or right.
2. Port “J” feeds left tip lift.
3. Port “E” feeds right tip lift.
4. Remove existing hose and fi tting from selected port.
5. Install small 9/16 ORB tee fi tting into port.
6. Install original hose to tee.
7. Remaining exposed tee port will be directed towards tractor remote and will be connected by supplied hose/
hoses, union as required, restrictor, and tractor coupler. Colored ties will mark each end of supply hose.
8. Hose may be clamped to sprayer hitch side frame with plastic clamps.
9. Recommended placement of restrictor is nearest the hydraulic coupler.
WARNING!
RESTRICTOR INCLUDED IN THIS PACKAGE IS FOR OPERATOR SAFETY. MODERN TRAC-
TORS HAVE TOO MUCH FLOW FOR OUR HYDRAULIC SYSTEM AND MAY PUT DAMAG-
ING STRESSES ON THE ULTIMATE BOOMS. FLOW CONTROLS ON THE TRACTOR ARE
ADJUSTABLE BUT ADJUSTMENTS, IF PERFORMED AT ALL, WILL VARY FROM OPERATOR
TO OPERATOR. FOR SAFETY AND SPRAYER LIFE THE RESTRICTOR MUST BE INSTALLED.
FAILURE TO DO SO COULD VOID ANY BOOM WARRANTY YOU HAVE.
After installation of this option the remote tip lift function will now be independent of the Ultimate switch box
on the one circuit only. The remaining tip lift could have the option installed also, or the switch on that tip lift
cylinder could be left on and the operator would then have separate control with two different hydraulic circuits.
The sprayer switch box will still function exactly the same as it had prior to the installation of the separate
control. Operator will have two different means of controlling the same circuit.
Parts required
Component Description Quantity per
8D3212 MALE TIP 3/4”-16ORB ISO 1.000
8G2286 NYLON TIE - BLUE 2.00
8J5100 * #6 JIC(M) X #6 JIC(M) UNION 1.000
8J5510 3/4” -16 ORB X #6 JIC(M) STR 1.000
8J5800 3/8”FPT X #6 JIC(F-SW) STR 1.000
8J6002 9/16”-18 ORB X #6 JIC(M) 1.00
8J7216 #6JIC(M) X #6JIC(F) 1/16”RESTR 1.000
8N3060 * 3/8 X 60”HYD HOSE #6FJX3000PSI 1.000
8N3348 3/8X 348”HYD HOSE #6FJX3000PSI 1.000
8S2980 HYD HOSE CLAMP-SMALL-NYLON 6.000
8X0202 NUT NY-LOCK 3/8”-16NC GR2 ZDI 3.000
* Not required on sprayer sizes less than 90 feet.
