SECTION 6 - OPTION NOTES AND INSTRUCTIONS
6.9
Loading Liquid or Powdered Chemical into Hopper
7. Pour required amount of chemical into hopper. Avoid splashing liquids or powdered chemicals outside of
hopper.
8. Rinse empty chemical containers if applicable. Place container opening over container rinse valve and
press down. This will activate the rinse valve and rinse container.
9. Rinse cleanload hopper. Close and lock lid by turning cover clockwise. Release the safety return locking
band to locked position.
10. Open lid and inspect for chemical residue. Repeat step 10 as necessary.
11. Close knife valve by pulling red handle out towards you. Turn inlet valve off.
Loading Liquid and or Powdered Chemical with Optional Suction Lance
Note: Lance suction is dependant on eductor pressure and fl ow. For best results use highest pressure avail-
able up to 150 PSI maximum.
12. Insert lance body with o-ring into eductor until the o-ring is sealed.
13. Use free end of lance to pierce bag or container and vacuum powdered or liquid chemical.
14. Rinse lance. Place lance end into a clean container of water to rinse lance assembly.
15. Remove lance body from eductor and drain any remaining fl uid into hopper.
16. Close knife valve by pulling red handle out towards you. Turn inlet valve off.
Shutdown
1. Close knife valve fi rst by pulling red handle out towards you.
2. Insure that the remaining valves are closed.
3. Verify chemical residue has been cleaned up.
4. Close hopper lid and lock by turning clockwise.
5. Divert pump discharge fl ow back to normal operation by closing valves “C” or “P”.
6.13. ELECTRIC AGITATOR SHUTOFF PACKAGE
To install Electric agitator shutoff on a Summers Pull-Type Sprayer
1. Install the mounting bracket on ball valve.
2. Locate 2” square tube on front of sprayer hitch where the mounting bracket will attach.
3. Attach mounting bracket and ball valve to square tube in line with existing agitator feed hose.
4. Install fi ttings into ball valve.
5. Cut existing agitator feed hose near ball valve shutoff and attach hoses to ball valve fi ttings.
6. Locate switch box accessory leads on right side of sprayer main frame or near hydraulic block on rear of
sprayer.
7. Connect ball valve wire harness to available lead.
8. Energize switch box and locate switch to controls agitator ball valve motor.
9. Agitator fl ow is regulated by manual ball valve on discharge plumbing.
10. Electric shutoff will enable and disable fl ow as desired.
