Summit BIM26H32 - Product Overview and Specs

1
Product Overview and Specs
Model
BIM26H32 / BIM26H34 / BIM27OSADA /
BIM271OS
Voltage/Frequency
AC 115V 60Hz
Rated Ice making current
1.9A
Rated Ice harvest current
1.5A
Refrigerant
R600a, 1.58Oz.
Indoor/Outdoor
Indoor/Outdoor*
IP Rating
IPX4
ADA
Yes
Installation Type
Free standing / Built-in
Working temperature
50
℉
- 100
℉
Working water pressure
20 ~ 80 Psi
Ice Storage Capacity
22 lbs. maximum
Ice-making Capability at 50
°
F
25 lbs./day**
Ice Shape
Crescent
Ice Cube Dimensions (Approximate)
1/2 "×3/4 "×2-3/8 "
Unit Dimension (W×D×H)
14-7/8 ''× 18-7/8 ''×31-7/8 ''
Net Weight
61 lbs.
* When used in a limited outdoor environment: the unit must be under the awning or the canopy
and shall not be exposed directly to rain.
**The actual quantity of ice produced per day will vary with ambient room and water conditions.
Note: Technical data and performance information are provided for reference only and subject to
change.
