Description of your oven
1. – Control Panel
5. – Convection output
9. – Rectangular Glass Tray
2. – Door window glass
6. – Turntable Support
10. – Rectangular Rack
3. – Lateral supports
7. – Turntable ring
4. – Catches
8. – Turntable plate
1. – Function selection keys
4a.-Power/Weight indication lights
2. – “+” and “–“ keys
5. – Clock/ Time selection key
3. – Oven Temperature selection key
5a.-Clock/ Time indication lights
3a.- Oven Temperature indication light
6. – Start and Stop/ Safety blocking keys
4. – Power/Weight selection key
1
5
2
3
4
6
7
9
8
10
3
300
1000
09:00
3a
4 4a
1
2
6
5a
5
