2.12 Half width shut off
As fitted to 6m and above drills
A deflector is moved to the left or right using an electronic actuator controlled from the cab instrument as
shown bellow. When half the drill is switched off the motor speed is halved at the same time
Seed is deflected to just one distribution head enabling the half width function.
When drilling at full width the actuator moves to the mid way position when the internal deflector (as
seen coloured red in picture) is vertical allowing even seed distribution across the drill width
