40
5.3 Seed depth
The seeding depth is altered by removing a 20mm pin and lifting or lowering the coulter.
For bean drilling a 1” seed boot can be fitted by removing roll pin.
5.4 Covering disc adjustment
The covering discs are very adjustable to suit different conditions via M8 bolts
5.5 Chassis adjustment
The chassis needs to be set so the chassis runs parallel to the ground
Shallowest
seed leg depth
Main chassis set parallel
with ground
