When removing pipes from the tractor make sure all hydraulic are fully open or fully closed before
applying float on the tractor.
The wings are fitted with check valves on the rams which allows them to be depressurised without
letting the wings unfold.
Change over tap for the wings and bout markers (4, 4.8 and 6m versions only) is located on the front of
the chassis beneath the hopper access steps.
The FREE FLOW RETURN for the fan must be connected before the fan is started; it has a
maximum return pressure of 15bar which can be read from the pressure gauge mounted next to the fan.
