Sun Hydraulics XMD-01 - Input Specifications; Environmental Specifications

www.sunhydraulics.com ©2017 Sun Hydraulics Corporation 8
XMD User Manual
TECHNICAL SPECIFICATIONS
Inputs
Universal Inputs
XMD-01 (1 universal input)
Maximum voltage on any input pin +32 V
DC
and
-0.7 V
DC
XMD-02 (2 universal inputs)
Input Types
0-5 V
DC
0 to +5 V
DC
0-10 V
DC
0 to +10 V
DC
Resistive
0-100 KΩ
0 to 100 KΩ
4-20 mA Maximum allowable current: +22
mA (impedance Z = ~200 Ω)
Active circuit protection above 22 mA and
limited to 32 V
DC.
Digital 0 to +Supply, not to exceed 32 VDC
(impedance Z = ~10 Ω)
Low is active when the input is <2 V
DC
, high is
active when the input is >3 VDC. A debounce
time of 200 ms is xed in device rmware.
Frequency
60 Hz - 10 kHz
Duty Cycle range: 5% to 95% at 5V
input
Amplitude minimum of 5V
DC
above ground.
Amplitude maximum of 32 V
DC
above ground.
PWM
60 Hz - 10 kHz
Range: 5% to 95% at 5V
DC
Range: 2.5% to 97.5% at >10V
DC
Frequency range: 60 to 10 kHz.
Amplitude minimum of 5 V
DC
above ground.
Amplitude maximum of 32 V
DC
above ground.
Environmental
Patent
Operating Temperature -40˚C to +85˚C
(-40˚F to +185˚F)
Vibration 33.3 Hz 6.8g Peak (Spec: S-367 Section 11.0)
Storage Temperature -60˚C to +120˚C
(-76˚F to +248˚F)
Shock 49g Peak (Spec: S-367 Section 12.0)
EMC/EMI EN 55024, EN 55032, EN 13309, EN/ISO 14982, ISO 13766, ISO 16750-2, J1113-
4/11/12/13/26, ISO 1142-2/10, CISPR 25, FCC 15B, ICES-003, UNECE REG 10.5,
EN 61326-1:2013, EN 301 489-1 V2.2.0, EN 301 489-17, EN 12895
Patent Number Patent Pending
