How to Add Components to Your Limited Configuration Server 5
Lock the Memory Mezzanine Tray
For server systems that use a memory mezzanine tray (for example, the Sun Fire
X4450), you must lock the mezzanine tray before you install or move the server.
Caution – Unsecured trays or cards are easily dislodged when shipped or moved.
● See the top cover service label for instructions about securing the mezzanine
tray.
Test Installed DIMMs
Verify that the server can see all installed DIMMs.
How to Add a DVD/USB Drive
■ The server ships with filler panels for a vacant DVD drive slot and each vacant
HD slot.
■ You must install the DVD drive/USB hub before you install the hard drives.
Testing Installed Memor y
• Reassemble the server and use one of the following methods to verify the
DIMMs:
• Boot from the Tools and Drivers CD/DVD and access the diagnostics by
selecting the option to run hardware diagnostics (option 1).
• Log in to the service processor’s (SP) ILOM using ssh or a browser and the IP
address of the SP.
Adding a DVD/USB Drive Unit
1
Eject all hard drives and HD filler panels.
2
Remove the DVD filler panel.
3
Slide the DVD/USB drive
*
unit into the DVD slot and engage the connector on
the backplane.
* Use the -09 (or later) revision of the DVD/USB drive unit.
4
Populate the HD slots with hard drives or hard drive filler panels.
5
Test the DVD drive by booting the server using the Tools and Drivers DVD and
accessing the Pc-Check diagnostics.
