2.2 Structure and Composition
The product adopts a modular design framework. The battery box, energy storage inverter and power distribution box
are installed in the form of components for easy replacement.
Picture 2-2 Product appearance
(1) Cabinet top cover
(8) Cabinet base
(2) LAMP button
(9) PCS air inlet
(3) Input and output cables hole
(10) Antenna
(4) Inverter air outlet
(11) Input and output cables hole
(5) Battery heat dissipation port
(12) Marks
(6) LCD display
(13) Heat dissipation port of the battery
(7) Cabinet front door
Picture 2-3 Internal composition of the product
(1) Inverter
(6) Circuit breaker switch
(2) Power distribution box
(7) LCD display
(3) Battery module
(8) LCD control board
(4) Start button
(9) Power module
(5) PV input terminal
(1)
(4)
(3)
(5)
(6)
(8)
(7)
(2)
(9)
(13)
(12)
(10)
(11)
(1)
(3)
(2)
(4)
(5)
(6)
(7)
(8)
(9)
