1.9.7.2 Ethernet
On this interface users can perform Ethernet connection for the controller.
step 1 Click SystemPort ParameterEthernet to enter the corresponding interface.
step 2 Set the Ethernet information as below.
• If Automatically Obtain IP Settings (DHCP) is
, the IP address corresponding to the
port is invalid and users can log in the device through the virtual IP address. The IP
address of each port is as follows.
table 1-2 Controller IP Address
Port Default IP address
ETH1 14.14.14.14
ETH2 12.12.12.12
ETH5 13.13.13.13
The above IP addresses are for reference only. The real IP addresses shall
prevail.
• If Automatically Obtain IP Settings (DHCP) is
, fill in the IP address, the subnet
mask, and the gateway address.
step 3 Click
on the right to save the settings.
- - End
1.9.7.3 WLAN
step 1 Click SystemPort Parameter WLAN to enter the corresponding interface.
step 2 Click
in AP hotspot enable switch.
• If it is set to Enable, the hotspot is enabled. And the following parameters should be set.
Parameter
Description
SSID
The name of the wireless local area
network (WLAN), which should be filled in
according to the actual situation.
Security
Please select the wireless network
encryption type based on the actual
situation.
– If there is no encryption, select "None”.
– If WPA2 is selected, the wireless
network can only be connected if the
correct password is entered.
