12
Item Name
Quantity
A Base 1
B
Battery module
3 - 8
C
Top cover
1
D
Switch gear
1
1
E Bracket 1
F Side cover 3 - 8
G Communication connector 1
H
M5*125 hex socket screw（optional）
1
I Foot 4
J M5*14 hex socket screw
2
14 - 24
K
Expansion plug set
2
L M5 screw sets
2
6
M M6 fender washer
2
5
N
SUNCLIX connector or MC4
Connector
1
O OT terminal 1
P
Communication cable fastening tool
1
Q
Documents 1
1. Images in this manual are for reference only. The actual product received may
differ.
2. The number of parts marked with “
2
” is greater than required. Please refer to
the installation steps for the specific quantity needed.
3.3 Storage
Proper storage is required if the battery is not installed immediately.
• Store the battery in the original packing case with the desiccant inside.
• Preferably, keep the temperature in the range of 15℃ - 25℃. Store the battery within the
temperature range of -10℃ to 35℃ for no more than 6 months.
• The storage relative humidity must be always between 0 and 95%, non-condensing.
• Store the battery in a clean and dry place, without exposure to sunlight and rain. The
storage location must be free of harmful gases, flammable/explosive products and corro-
sive chemicals. The battery should be prevented from mechanical impact, high pressure,
high-intensity magnetic field and direct exposure to sunlight.
• Pay attention to the harsh environment, such as sudden cooling/heating and collision, to
avoid damage to the battery.
• The number of stacking layers of battery modules with package must not exceed 6. It is
strictly forbidden to directly stack batteries without package.
• Regularly inspect the package for damage and insect bites. If any damage is found, the
product should be replaced immediately.
3 Unpacking and Storage User Manual
