Sungrow SG25CX-P2 User Manual

10
Dimensions
The following figure shows the dimensions of the inverter.
figure 2-3 Product Dimensions(in mm)
Weight
Model Dimensions (W*H*D) Weight
SG25/30/33CX-P2
645*575*245 mm
38 kg
SG36/40CX-P2 40 kg
SG50CX-P2 41 kg
SG30CX-P2(For Australia)
600*625*240 mm
35 kg
SG50CX-P2(For Australia) 36 kg
2.3 Symbols on Product
Symbol Explanation
Do not dispose of the inverter together with household waste.
Read the user manual before maintenance!
TÜV mark of conformity.
Regulatory compliance mark.
CE mark of conformity.
EU/EEA Importer.
RoHS labeling
The product complies with the requirements of the applicable
EU directives.
2 Product Description User Manual

Sungrow SG25CX-P2 Specifications

General

Rated Output Power	25 kW
Max. Input Voltage	1100 V
Start Voltage	200 V
Number of MPPTs	2
Number of DC Input Connections per MPPT	2
Max. AC Apparent Power	27.5 kVA
Total Harmonic Distortion	< 3%
MPPT Voltage Range	200-1000 V
AC Voltage Range	310-480 V
Rated Grid Frequency	50/60 Hz
DC Switch	Yes
Protection Class (According to IEC 62103)	I
Operating Temperature Range	-25°C to 60°C
Warranty	10 years
