16
5 LCD Operation
5.1 Main Screen
After successful commissioning, the LCD screen will enter the main screen.
Pac
:
Status
:
3456
W
Running
Inverter power
Inverter status
If there is no button operation for:
1 minute, LCD backlight will be automatically deactivated;
2 minutes, system will return to the default screen (main screen).
When there is no button operation for 8 seconds on the main screen, the LCD
screen will automatically go through the main screen and energy, PV and grid
interfaces, with each interface stayed for 2 seconds. Quit this mode by any
operation on any button.
E-total: 1999kWh
E-today: 20.0kWh
Ipv: 2.9A
Grid Vtg:
Grid Frq:
221.7V
50.0Hz
Vpv: 250.0V
Pac:
Status:
3456W
Running
* The images shown here are for your reference only. For -D series, all PV input
information will be displayed.
Tab. 5-1 Status Description
The inverter waits for sufficient sunlight, then the DC voltage
recovers.
The inverter is initializing and synchronizing with the grid.
After being energized, the inverter tracks the PV strings’
maximum power point (MPP) and feeds the AC power to grid.
This mode is the normal mode.
The inverter will stop running by manual “OFF” via the LCD
menu. Set to “ON” if you want to restart the inverter.
The DSP or LCD program is upgrading.
