CONNECT POWER CABLES
1
OPEN BATTERY
400.0
V
V
+
-
AWG #10-12
BAT
1)CAN_H
2)Enable_GND
3)Enable_H
4)RS485_H
5)RS485_L
6)CAN_L
6
ATTACH COMMUNICATION CABLES
5
CONNECT INVERTER
AWG #10-12
BAT
1)CAN_H
2)Enable_GND
3)Enable_H
4)RS485_H
5)RS485_L
6)CAN_L
182
INSTALLATION &
COMMISSIONING
WITH LG BATTERY
3 CHECK CABLE POLARITY
4
ASSEMBLE SUNCLIX CONNECTOR
400.0
V
V
+
-
7 SWITCH ON BATTERY
8
OPEN iSolarCloud
10 min
5.5 - 8 mm
2
Ø
16 mm
2 N• m
15 mm
4:34 PM
100%
SH6.0RT OFFICE
Yield Today
6,6 kWh
Log
MoreRun-InfoHome
Plant Status
Overview Devices
Normal
BACK
Installed Power 7,26 kWp
Real-Time Power
1,43 kW
100%
0 W 345 W
1,49 kW 1,43 kW 1,09 kW
4:34 PM
100%
SH6.0RT OFFICE
BACK
General Information Active Faults
Battery
Charging Power
Battery
Voltage
Battery
Current
Battery
Level
Battery
Health
Battery
Temperature
Battery
Discharging Power
Max. Charging
Current (BMS)
Max. Discharging
Current (BMS)
Daily PV
Battery Charging
Energy
0
397,7
0,1
100
100
24
0
0
30
4,5
W
V
A
%
%
°C
W
A
A
kWh
4:34 PM
100%
SH6.0RT OFFICE
Ertrag heute
6,6 kWh
Log MehrBetriebsdatenHome
Anlagenstatus
Übersicht Geräte
Normal
ZURÜCK
Installierte Leistung 7,26 kWp
Aktuelle Leistung
1,43 kW
100%
0 W 345 W
1,49 kW 1,43 kW 1,09 kW
