5
Know Your Cordless Grass Shear + Shrubber
Read the owner’s manual and safety rules carefully before operating your cordless grass shear + shrubber. Compare the
illustration below to the actual unit in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
Technical Data
Charger Input 120 V
Charger Output 6 V
600 mA
Battery Voltage 3.6 V
Battery Capacity 1.5 Ah
Battery Type Lithium-iON
Shear Blade Length 3.3 in. (8.4 cm)
Shrubber Blade Length 5 in. (12.7 cm)
No Load Speed 900 rpm
Charger Included
Battery Runtime (Max) 45 min
Charging Time 3 hours
Weight 2.1 lbs (1 kg)
1. Charging socket
2. Charging indicator
3. Handle
4. Power ON/OFF trigger switch
5. Safety lock-o button
6. Safety tabs
7. Grass shear blade
8. Shrubber blade
9. Charger adapter
10. Charger plug
11. Grass blade sheath + shrubber blade sheath
(not shown)
1
2
35
6
7
8
9
Back of the handle
4
10
The other side of the unit
