Sunny SF-E3959 - PARTS LIST; Ordering Replacement Parts

4

PARTS LIST
No. Description Spec. Qty No. Description Spec. Qty
1 Main Frame 1 22 Bearing 4
2R Pedal Tube (R) 1 23 Nylon Nut M8 6
2L Pedal Tube (L) 1 24 Screw ST4.2*15 10
3 Crank 2 25 Flange Nut M10 2
4 Power Cord 1 26 End Cap 2
5 Power Switch 1 27 Rubber Washer 2
6 Rubber Pad 2 28 3P Data Line 1
7L/R Pedal 2 29 Sensor 1
8L/R Belt Cover 2 30 Screw M3x8 2
9 Motor 1 31 Fixing Bolt 4
10 Console 1 32 6P Data Line 1
11 Remote Control 1 33 Screw M5x16 6
12 Controller 1 34 Spring Washer Φ2.7*Φ4.2*1.1
6
6
13 Outlet 1 35 Flat Washer Φ5.5*Φ10*1 6
14 Slide Wheel 2 36 Screw M4x10 1
15 Silicone Pad 2 37 Spring Washer Φ2.2*Φ3.4*0.8 1
16 End Cap 2 38 Non-Slip Pad 1
17 Bolt M8*45*15 4 39 Screw ST3.5*15 1
18 Alloy Wrap 4 40 Flat Washer Φ16.2xΦ28x1.2 2
19 Flat Washer Φ8.2*Φ25*1.5 2 41 Sleeve 4
20 Screw M8*16 2 42 Screw M3*5 4
21 Hex Bolt M8*45*15 2 43 Washer Φ70*1.0 1
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify the part(s) needed:
 The model number (found on cover of manual)
 The product name (found on cover of manual)
 The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST” (found near the front
of the manual)
Please contact us at support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).
