SunSetter Wireless Wind Sensor User Manual

6
Appendix A
Changing the Direcon of Motor Rotaon for the RTS Motor ONLY.
The RTS Motor can be idened by the Black Motor with a Square Case and
Mechanical Stops.
This procedure describes the acons needed to change the direcon of Motor
rotaon, and should only be performed when installing a Wireless Wind Sensor if the
lower buon on your Remote is not the buon that opens your Awning.
Review the steps below to familiarize yourself with the procedure before aempng
to complete them.
1. Verify that the red light on the exisng Remote Transmier comes on when you
press a buon. If the red light does not come on at all or stays on for less than ve
(5) seconds, you will need to replace the baery.
2. Make sure your Awning is retracted against the house (closed).
3. Press the my (middle) buon on the Remote Transmier.
4. Unplug the power cord from the wall.
5. Insert the Crank Wand into the Override Crank on the Motor and manually open the Awning approximately
three (3) feet but do not completely open the Awning.
6. Plug the power cord back into the wall and make sure that there is electricity available. Let the Awning sit
for one minute, undisturbed, without pressing a buon on the Remote Transmier or unplugging the power
cord from the wall.
7. Unplug the power cord from the wall for two (2) seconds.
8. Plug the power cord back in for ten (10) seconds.
9. Unplug the power cord for two (2) seconds.
10. Plug the power cord back in and leave it plugged in.
Note: The Motor may rotate approximately two (2) feet in one direcon and stop.
11. When the Motor stops, press and hold the Programming Buon on the back of the Remote Transmier for
5 seconds unl the motor ‘jogs’, then release. (A ‘jog’ is a short back and forth movement of the Motor).
12. Acvate the Transmier by pressing the OPEN and CLOSE buons at the same me, the Motor will jog.
13. Press the my (middle) buon on the front of the Remote Transmier unl the motor jogs, then release.
14. Press the Programming buon on the back of the Remote Transmier unl the motor jogs and release.
The direcon of the Motor rotaon has been changed.
Test the Awning for proper operaon. Make sure that the lower buon on the Remote extends the Awning
out.
Mechanical Stops
Black Motor with
a Square Case
