WTP-801 User Manual
11
4 INSTALLATION AND USAGE
4.1 Media Loading
4.1.1 Paper Confirmation
1) When using 80mm(width) roll paper, take out the paper guide of both sides.
2) When using 58mm(width) roll paper, insert the paper guides to each side.
Note: Roll paper should be placed in the middle.
4.1.2 Paper Loading
1) Pull the cover open button to open the printer cover.
2) Remove the used roll paper core, if any.
3) Load the paper roll in the correct direction as shown below.
