7
SPS/D(C)-1202 Series are made for industrial use to perform button sewing to
fabrics or its similar materials. Please observe the following principles.
ⓐ Read the manual to understand on the operation of machine perfectly.
ⓑ Wear suitable clothes and cap for safe operation.
ⓒ During operation, don’t make you body close to operating part of machine such
as needle, hook, take-up lever or pulley.
ⓓ Do not remove a safety plate and covers during operation
ⓔ Be sure the grounding lines in connected.
ⓕ Before opening electricity box such as control box, cut off the supply of
electricity and confirm if the switch is “off”.
ⓖ When inserting thread into a needle or before inspecting after sewing, be sure
the machine is stopped.
ⓗ Do not turn on the power during pedaling.
ⓘ Do not use several motor per a electric outlet.
ⓙ Install the machine apart from noise occurrence area such as high frequency
welding machines as far as possible.
ⓚ Be careful- When the upper feed plate comes down to press. Otherwise, the
finger or hand hight be hurt at smacking.
1-4) Machine Operation
Warning
ⓐ Safety label : It describes cautions during operating the machine.
ⓑ Thread take-up cover : It prevents from any contact between body and take-up lever.
ⓒ Motor Cover(D Series) : It prevents from insertion of hands, feet or clothes by Motor.
Belt Cover(C Series) : It prevents from insertion of hands, feet or clothes by V-belt Motor.
ⓓ Label for specification of power : It describes cautions for safety to protect against
electric shock during rotating the motors.
ⓔ Finger guard : It prevent from contacts between a finger and needle.
ⓕ Safety plate : It protects eyes against needle breaks.
1-5)
Devices for safety
Notice
Belt will crush or amputate finger or hand, keep cover in place
before operating, turn off power before inspecting or adjusting.
Warning
ⓑ
ⓐ
ⓕ
ⓔ
ⓓ
ⓒ
To Next Page
