SunStar SWF/B-T1201C - GREASE SUPPLY GUIDELINES

120
SWF/A-T1201C
SWF/A-T901C
SWF/A-T601C
250V/6.3A
(20mm)
250V/4A
(20mm)
250V/6.3A
(20mm)
250V/1A
(20mm)
F1
(Main Power)
F2
(Trimming,
Picker Solenoid)
F3
(Jump Solenoid,
Color Change Motor)
F4
(Wiper Motor)
Kinds
Fuse Capacity
FUSE LOCATION ON 220V POWER BOARD
