133
Presser Foot Holder
Screw
Washer
Presser Foot
Needle
ADJUSTING THE HEIGHT OF THE PRESSER
FOOT
Use the hand wheel to check what the relation
between the presser foot and the needle will be
when embroidering. Set the needle bar to 180
degrees. Remove the plate on the sides and loosen
the joint screw of the presser foot. Adjust the space
between the bottom of the presser foot and the upper
part of the needle plate to accomodate the material
being embroidered (K). Refasten the joint screw
snugly. Repeat for each presser foot.
Standard Setting Value
Needle plate for cap = 1.5mm
Needle plate for flats(tubular) = 1mm
