SunStar SWF/B-T1201C - TABLE ASSEMBLY PROCEDURES

11
TABLE ASSEMBLY
1) When using the border frame, attach the table ⓑ
to the main body of the machine.
2) Attach the table ⓑ to the machine by inserting
the table supporting plate into the table pressing
plate as shown. When assembly is complete,
fasten it with the table fixing screw.
Table Screw
Table
Table Supportting Plate
Table Pressing Plate
Table
Table Screw
