TEMPERATURE ADJUSTMENT
A – Reset button (only for TLSC)
B – Knob for temperature adjustment
schema 8
schema 6
NOTE: See Figure 6.
To close the front part, the cartridge
opening must align with the coupling of
the adjustment knob.
CONNECTION LIMITATION
TERMINAL 2–opensthecircuitwhenthe
temperaturerises.
TERMINAL C–commoncontact.
THERMOSTAT
TERMINAL 1–opensthecircuitwhenthe
temperaturerises.
TERMINAL 2–closesthecircuitwhenthe
temperaturerises
TERMINAL C–commoncontact
schema 7
