6.TECHNICALPARAMETERSBUFFERS-РSseries
6.1. Model PS - without coil /150L - 200 L/
PS
150
PS
200
Capacity L 150 200
Height H,mm 1310 1710
Minimalvercalclearance mm 1400 1780
Diameterwithoutinsulaon/withinsulaon D,mm Ø400/500 Ø400/500
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95
Recommendedboilersize,connectedtobuertank kW 6-10 6-10
Weight kg, 38 47
SleeveforElectricheangelement В,mm,Rp1
1/2”
755 995
Heatcarrier С1,mm,Rp1
1/2”
185 185
Heatcarrier С2,mm,Rp1
1/2”
185 185
Heatcarrier С3,mm,Rp1
1/2”
485 725
Heatcarrier С4,mm,Rp1
1/2”
485 725
Heatcarrier С5,mm,Rp1
1/2”
885 1165
Heatcarrier С6,mm,Rp1
1/2”
885 1165
Heatcarrier С7,mm,Rp1
1/2
” 1125 1525
Heatcarrier С8,mm,Rp1
1/2
” 1125 1525
Sensorsleeve А1,mm,Rp1/2” 185 185
Sensorsleeve А2,mm,Rp1/2” 485 725
Sensorsleeve А3,mm,Rp1/2” 885 1165
Sensorsleeve А4,mm,Rp1/2” 1125 1525
Airventsleeve F,mm,Rp1
1/2
” 1310 1710
