Sunsystem PS Series - 3 TECHNICAL PARAMETERS BUFFERS - Р Series

14
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL INSTALLATION and OPERATION MANUAL
3.TECHNICALPARAMETERSBUFFERS-Рseries
3.1.ModelР-
without coIl
P 300 P 500 P 800 P 1000
Capacity L 300 500 800 1000
Heightwithoutinsulaon/withinsulaon H,Hi,mm 1410/1460 1610/1660 1860/1910 2040/2090
Minimalvercalclearance mm 1430 1640 1900 2075
Diameterwithoutinsulaon/withinsulaon D,mm Ø650/750 Ø650/850 Ø790/990 Ø790/990
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95 3/95 3/95
Recommendedboilersize,connectedtobuertank kW 6-10 10-17 15-27 18-33
Weightwithoutinsulaon/withinsulaon kg,kgi 60/70 90/102 118/134 133/151
SleeveforElectricheangelement В,mm,Rp1
1/2
” 760 790 920 1130
Heatcarrier С1,mm,Rp1
1/2
” 1170 1370 1573 1742
Heatcarrier С2,mm,Rp1
1/2
” 1390 1520
Heatcarrier С3,mm,Rp1
1/2
” 880 990
Heatcarrier С4,mm,Rp1
1/2
” 770 880 980 1060
Heatcarrier С5,mm,Rp1
1/2
” 540 620 670 730
Heatcarrier С6,mm,Rp1
1/2
” 150 150 170 170
Heatcarrier С7,mm,
Heatcarrier С8,mm,Rp1
1/2
” 660 770 820 880
Heatcarrier С9,mm,Rp1
1/2
” 260 250 310 310
Sensorsleeve А1,mm,Rp1/2” 410 410 570 580
Sensorsleeve А2,mm,Rp1/2” 1060 1120 1290 1500
Sensorsleeve А3,mm,Rp1/2” 1010 1120 1290 1450
Sensorsleeve А4,mm,Rp1/2” 420 460 465 495
Airventsleeve F,mm,Rp1
1/2
” 1410 1610 1860 2040
