INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
P 1500 P 2000 P 2500 Р3000 P 5000
Capacity L 1500 2000 2500 3000 5000
Heightwithoutinsulaon/withinsulaon H,Hi,mm 2150/2220 2132/2182 2482/2532 2246/2296 2940/2990
Minimalvercalclearance mm 2220 2220 2542 2332 3066
Diameterwithoutinsulaon/withinsulaon D,mm Ø1000/1200 Ø1200/1400 Ø1250/1450 Ø1400/1600 Ø1600/1800
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95 3/95 3/95 3/95
Recommendedboilersize,connectedto
buertank
kW 27-50 36-67 46-84 55-100 91-167
Weightwithoutinsulaon/withinsulaon kg,kgi 206/229 273/300 305/335 402/437 585/625
SleeveforElectricheangelement В,mm,Rp1
1/2
” 1130 1170 1170 1184 1505
Heatcarrier С1,mm,Rp1
1/2
” 1808 1775 2126 1797 2438
Heatcarrier С2,mm,Rp1
1/2
” 1635
Heatcarrier С3,mm,Rp1
1/2
” 1305 1420 1474 2115
Heatcarrier С4,mm,Rp1
1/2
” 1085 1170 1420 1184 1735
Heatcarrier С5,mm,Rp1
1/2
” 765 735 735 864 1155
Heatcarrier С6,mm,Rp1
1/2
” 235 230 230 344 385
Heatcarrier С7,mm, Rp1/2”/975 Rp1
1/2
”/1170
Heatcarrier С8,mm,Rp1
1/2
” 895 980 980 1082 1373
Heatcarrier С9,mm,Rp1
1/2
” 375 380 380 477 518
Sensorsleeve А1,mm,Rp1/2” 875 920 920 910 951
Sensorsleeve А2,mm,Rp1/2” 1500 1645 1645 1660 2001
Sensorsleeve А3,mm,Rp1/2” 1525 1625 1625 1590 2231
Sensorsleeve А4,mm,Rp1/2” 520 500 500 610 691
Airventsleeve F,mm,Rp1
1/2
” 2150 2132 2482 2246 2938
