Sunsystem PS Series - 7 TECHNICAL PARAMETERS BUFFERS - РSM Series

35
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
INSTALLATION and OPERATION MANUAL
7.МodelPSM-withoutcoil/30L-100L/
PSM
30
PSM
50
PSM
80
PSM
100
Capacity L 30 50 80 100
Heightwithoutfeet H,mm 360 520 755 915
Diameterwithinsulaon D,mm Ø 440 Ø 440 Ø 440 Ø 440
Operangpressure/Max.buertemperature bar/
0
C 6/95 6/95 6/95 6/95
Recommendedboilersize,connectedtobuertank kW 1-4 3-5 6-10 6-10
Weight kg, 13 17 25 29
Connecon А1,A2mm,Rp1
1/2”
180 170 190 230
Connecon B1,B2mm,Rp1
1/2”
- 355 315 380
Connecon F1,F2mm,Rp1
1/2”
- - 440 535
Connecon G1,G2mm,Rp1
1/2”
- - 570 690
Connecon J,mm,Rp1
1/2”
360 520 755 915
Connecon Kmm,Rp1
1/2”
Rp1
1/2”
Rp1
1/2”
Rp1
1/2”
Rp1
1/2”
Dimensions M,mm 210 370 165 165
Dimensions N,mm - - 605 765
Distancebetweensuspension
holes of the wall mount
Х,mm, 240 240 240 240
N
J
K (Rp1
1/2
”)
H
B1
M
G1
F1
A1
A2
B2
F2
G2
X
A1
A2
B1
B2
J
H
M
A1
A2
M
H
J
X
X
K (Rp1
1/2
”)K (Rp1
1/2
”)
PSM 30 PSM 50
PSM 80-100
