6.3.МodelPS2-withtwocoils
PS 2
150
PS 2
200
Capacity L 150 200
Height H,mm 1310 1710
Minimalvercalclearance mm 1400 1780
Diameterwithoutinsulaon/withinsulaon D,mm Ø400/500 Ø400/500
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95
Operangpressure/Max.coiltemperature bar/
0
C 16/110 16/110
Recommendedboilersize,connectedtobuertank kW 6-10 6-10
Weight kg, 69 91
SleeveforElectricheangelement В,mm,Rp1
1/2”
755 995
Heatcarrier С1,mm,Rp1
1/2”
185 185
Heatcarrier С2,mm,Rp1
1/2”
185 185
Heatcarrier С3,mm,Rp1
1/2”
485 725
Heatcarrier С4,mm,Rp1
1/2”
485 725
Heatcarrier С5,mm,Rp1
1/2”
885 1165
Heatcarrier С6,mm,Rp1
1/2”
885 1165
Heatcarrier С7,mm,Rp1
1/2
” 1125 1525
Heatcarrier С8,mm,Rp1
1/2
” 1125 1525
Sensorsleeve А1,mm,Rp1/2” 185 185
Sensorsleeve А2,mm,Rp1/2” 485 725
Sensorsleeve А3,mm,Rp1/2” 885 1165
Sensorsleeve А4,mm,Rp1/2” 1125 1525
Airventsleeve F,mm,Rp1
1/2
” 1310 1710
Capacitylower/uppercoilS1/S2 S1/S2L 6.8/4.1 9.9/6.2
HeatexchangesurfaceS1/S2 S1/S2m
2
1.1/0.66 1.6/1.0
Inlet/OutletLowercoiS1 S1i/S1o,mm,Rp1” 705/185 945/185
Inlet/OutletUppercoilS2 S2i/S2o,mm,Rp1” 1125/805 1525/1045
