PR 1500 PR 2000 PR 2500 PR 3000
Capacity L 1500 2000 2500 3000
Heightwithoutinsulaon/withinsulaon H,Hi,mm 2150/2220 2132/2182 2482/2532 2246/2296
Minimalvercalclearance mm 2220 2220 2542 2332
Diameterwithoutinsulaon/withinsulaon D,mm Ø1000/1200 Ø1200/1400 Ø1250/1450 Ø1400/1600
Operangpressure/Max.buertemperature bar/
0
C 3/95 3/95 3/95 3/95
Operangpressure/Max.coiltemperature bar/
0
C 16/110 16/110 16/110 16/110
Recommendedboilersize,connectedtobuertank kW 27-50 36-67 46-84 55-100
Weightwithoutinsulaon/withinsulaon kg,kgi 272/295 330/356 362/392 476/511
SleeveforElectricheangelement В,mm,Rp1
1/2
” 1130 1170 1170 1184
Heatcarrier С1,mm,Rp1
1/2
” 1808 1775 2126 1797
Heatcarrier С2,mm,Rp1
1/2
” 1635
Heatcarrier С3,mm,Rp1
1/2
” 1305 1420 1474
Heatcarrier С4,mm,Rp1
1/2
” 1085 1170 1420 1184
Heatcarrier С5,mm,Rp1
1/2
” 765 735 735 864
Heatcarrier С6,mm,Rp1
1/2
” 235 230 230 344
Heatcarrier С7,mm, Rp1/2”/975 Rp1
1/2
”/1170
Sensorsleeve А1,mm,Rp1/2” 875 920 920 910
Sensorsleeve А2,mm,Rp1/2” 1500 1645 1645 1660
Sensorsleeve А3,mm,Rp1/2” 1525 1625 1625 1590
Sensorsleeve А4,mm,Rp1/2” 520 500 500 610
Airventsleeve F,mm,Rp1
1/2
” 2150 2132 2482 2246
CoilcapacityS1 S1L 21 24.6 24.6 29.9
HeatexchangesurfaceS1 S1m
2
3.4 4.0 4.0 4.9
Inlet/OutletLowercoilS1 S1i/S1o,mm,Rp1” 895/375 980/380 980/380 1082/477
