80-0056-00-SM-RevD 2017-12-13 SunTech Tango M2 Service Manual | 12
97-0191-00 when LCD lifted
97-0144-00 (original LCD)
8.1.1 Place the Tango M2 display downwards on a soft surface. Remove the four screws located in the
wells on the rear enclosure. The warranty seal must be broken to access all of the screws.
K-Sound Cable
Screw Locations
Keypad
Cable
Pneumatic Tubing
Internal ECG
Cable
