80-0056-00-SM-RevD 2017-12-13 SunTech Tango M2 Service Manual | 14
Appendix 1
Tango M2 Spare Parts List
PART NUMBER DESCRIPTION
99-0027-39 Tango M2 Preventative Maintenance Kit (Contains 1 Adult Plus cuff with
microphone, 1 Adult Large cuff with Microphone, and 1 Tango M2 Patient
Cable).
92-0140-00 Tango M2 K-DKA Board, Tested
98-0030-00 T-tube kit (For calibration – English Only)
58-0029-01 Keypad overlay w/lens
55-0119-00 Pump
55-0093-00 Valve (linear)
55-0043-05 Valve (dump)
55-0143-00 Valve (step)
39-0112-00 Enclosure, Tango M2, Front
39-0101-00 Light pipe (for LED on front enclosure)
39-0102-00 Power button (attaches to power switch)
39-0106-00 Enclosure, Tango M2, Rear
42-0002-00 Hole plug (non-ECG units only)
Appendix 2
Key to Exploded Views
Drawing Reference
(97-0144-XX-AD)
Quantity Part Description
SunTech
Part Number
FH1 1 Front Cover Subassembly 39-0112-00
LP1 1 LED Light Pipe 39-0101-00
LENS1 1 Lens w/Lens Overlay 58-0029-01
DISP1 1 LCD 26-0012-00
PWA2 1 Tango M2 UI Board 92-0139-00
PWA1 1 Tango M2 I/O Board 92-0138-00
PB1 1 Power Button 39-0102-00
M1 4 Pump 55-0119-00
MT1 1 Pump Mounting Tray 39-0094-00
LBL1 1 Device Label 71-0369-00
FT1 4 Rubber foot 42-0001-00
RH1 1 Rear Housing 39-0106-00
