Installation-Assembly Procedures
Assembly Procedures
Hardware Inventory
Before you begin, use the utility knife to cut open the Hardware Box and remove
the small bag of hardware. In addition to a small allen wrench and pillow, make sure
you have the following hardware items.
Allen-Head Bolt 5/16" x 1" - Quantity 8
(6 bolts may be pre-installed in bench bottom)
Bushing - Quantity 2
5/16" Metal Washer - Quantity 2
5/16" Metal Washer - Quantity 6
(May be pre-installed in bench bottom.)
Nylon Washer - Quantity 2
Phillips or Allen Head Bolt 5/16" x 1 1/2" - Quantity 2
Remote Bypass - Quantity 1
Hinge Brackets - Quantity 2
Safety Goggles - Quantity 1
Left Right
