5
Installation-Assembly Procedures
Attaching Legs to Bench
Lay the bench upside down on the floor. Locate the two legs and attach to the
bench as shown below.
1. Using the 5/16" x 1 1/2" bolts and the six larger sized 5/16" washers, attach the
legs with the skirt mounting holes toward the back of the bed as shown. Install cen-
ter bolt first. You may have to gently push sides of legs in to align holes. Tighten with
allen wrench.
2. Turn bench right side up on floor. Place so that power cord connector is facing
toward wall outlet.
SKIRT MOUNTING HOLES
BACK (POWER CORD SIDE) OF BED
