9.2.2 Then, LCD screen will show 1st page content of screen.
Press▼(-) key to browse 2nd page content of screen.
Press▼(-) key to browse 3rd page content of screen
Press▼(-) key to browse 4th page content of screen
Press▼(-) key to browse 5th page content of screen
If you stop pressing any key for 60 seconds approximately, the LCD would
showing back to first browsing page content.
Ub: voltage of batteries
Eb: mean power volume of battery with
percent format
Uw：meaning voltage of wind-turbine, but this
value is DC voltage, which be rectified
voltage from wind-turbine output.
Iw：charging current from wind-turbine to
battery.
System is initial …
Please wait…
Ub : xx.x V
Eb : xxx%
Uw : xx.x V
Iw : xx.x A
Us：mean solar panel voltage
Is：charging current from solar panel to
battery.
Us : xx.x V
Is : xx.x A
Output is turn-on, will show ―ON night‖ and
if output was turn-off, will show ―OFF
day‖ characters
Output
ON night
BATTERY
normal
It will show ―normal‖ while battery voltage
is good condition, and will show ―float‖
when floating charge states.
