11. System setting Instructions
“ENTER” key：symbolizes set or confirm: press this key to access setting
window. In setting window, press this key to choice each parameter and
go to next page.
“Esc” key: cancel or manual switch. In setting window, press this key to
return to browsing window and do not save the modified parameters.
11.1 Press ―ENTER‖ to access following content of screen firstly.
Press ▲(+) key or ▼(-) key to adjust the value, each press means
increase or reduce 0.1V.
11.2 Press ―ENTER‖ key to next page:
Press ▲(+) key or ▼(-) key to adjust the value, each press means
increase or reduce 0.1V. Press ―ENTER‖ to choose.
11.3 Press ‗ENTER‘ key to next page:
Press ▲(+) key or ▼(-) key to adjust the number, each press means
increase or reduce 0.1V. If set time, each press means increase or reduce 1
hour while setting time. Press ‗ENTER‘ to choose.
11.4 Press ‗ENTER‘ key to next page:
Press ▲(+) key or ▼(-) key to adjust the number, each press means
increase or reduce 1 hour. Press ―ENTER‖ to choose.
V1：Battery over-discharge voltage
V2：Battery over-discharge recovery
voltage
V1 : xx.xV
V2 : xx.xV
V3 : xx.xV
V4 : xx.xV
V5: floating charge voltage
T1-1: Line1 whole power output
time
V3：Battery over-charge voltage
V4：Battery over-charge recovery
voltage
V5 : xx.xV
T1-1 : xxh
T1-2 : xxh
T1-3 : xxh
T1-2: Line1 half-power output
time
T1-3: Line1 Turn-off output time
