14. Performance Parameters
14.1 Wind generator control set-up definition:
Rated Wind Turbine Power
200W – 600W
Wind Turbine brake voltage (12v/24v)
15VAC / 25VAC
Wind Turbine brake current (12v/24v)
10A / 20A
14.2 Solar panel set-up definition
PV max power (12v/24v)
150W / 300W
PV max open circuit voltage (12v/24v)
24.0V / 48.0V
PV max charge current
12.5A
14.3 Battery management definition
Over-discharge Voltage （12V/24V）
10.5V / 20.0V
adjustable
Over-discharge Recovery Voltage (12V/24V）
12.0V / 24.0V
adjustable
Over-charge Voltage（12V/24V）
15.0V / 30.0V
adjustable
Over-charge Recovery Voltage（12V/24V）
13.5V / 27.0V
adjustable
14.4 Output Set-up function:
Each Line Output Current rating
5A
Each Line Output rated Power (12V/24V)
60W / 120W
Dusk and dawn threshold voltage ( VsTH)
default : 6.0V
adjustable
14.5 Product Conventional parameter
Display
LCD with backlight
Self-consumption
≦30mA (backlight turn-off)
Temperature-compensation coefficient
-35mV/℃ (25℃ ref.)
Ambient temp. range
-30℃ to +55℃
Store temp. range
-35℃ to +80℃
Humidity range
10% - 90% (NC）
Altitude work
≤5000 meters above sea level
Protection class
IP55
Data-communication
RS232 / RS485/USB be optional
