Sunways STT Series - Mounting

 


※ 4.2 Mounting
① Use the inverter back bracket as the template to mark the position of 6 holes on installa-
tion bracket.
② Use an electrical driller with 12mm diameter bit to drill 6 holes on the installation brack-
et. See Figure 4-5 for details:
Figure 4-5 Mark the hole position
Figure 4-4 Dimensions of wall bracket
4.2.1 Wall bracket installation
Dimensions of wall bracket, see Figure 4-4:
Figure 4-6 Fixing the bracket
 
󽗊

󽗉
Figure 4-7 Mounting the inverter
4.2.2 Mounting the inverter
4 Installation 4 Installation


 


12mm
Handle
Handle
